Tag: bolt

  • Wood Screws

    Wood Screws

    Wood screws: These screws have a sharp point and a coarse thread that can cut into wood and create a strong bond. They are used for carpentry, furniture, and woodworking projects. Wood screws can have different head styles, such as slotted, Phillips, or square, and different shank styles, such as plain, tapered, or shanked.

  • Self Drilling Screws

    Self Drilling Screws

    Self-drilling screws: These screws have a drill bit point and a thread that can drill and tap into the material in one operation. They are used for fastening metal, wood, or composite materials. Self-drilling screws can have different head styles, such as hex, pan, or wafer, and different drive styles, such as slotted, Phillips, or…

  • Screws

    Screws

    Screws are types of fasteners that have a helical thread on a cylindrical shaft and a head on one end. They are used to join objects together by creating an internal thread in the material or by mating with a female thread. Screws can be made of different metals, such as steel, brass, or stainless…

  • U-Bolt

    U-Bolt

    A U-bolt is a type of bolt that has a U-shaped curve and threads on both ends. It is used to support or clamp pipes, rods, or cables in various industries, such as piping, transportation, and construction. U-bolts can be made of different materials, such as carbon steel or stainless steel, and can have different…

  • Conduit Support

    Conduit Support

    Bolt Clamp Channel Galvanized Steel Conduit Support Fitting See Detail A Conduit Conduit Clamp Channel Galvanized Steel Expansion Bolt C-shape Galvanized Steel Galvanized Steel Rod
