Tag: i beam cad block

  • I 250x125x7.5×12.5

    I 250x125x7.5×12.5

    —

    by

    draftsman
    in

    I 250x125x7.5×12.5 I-Beams with Tapered Inner Flange Surfaces refer to : JIS G 3192 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 250x125x7.5×12.5 Depth : 250 mm Width : 125 mm Web Thickness : 7.5 mm Flange Thickness : 12.5 mm Root Fillet Radius : 12 mm…

  • I 200x150x9x16

    I 200x150x9x16

    —

    by

    draftsman
    in

    I 200x150x9x16 I-Beams with Tapered Inner Flange Surfaces refer to : JIS G 3192 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 200x150x9x16 Depth : 200 mm Width : 150 mm Web Thickness : 9 mm Flange Thickness : 16 mm Root Fillet Radius : 15 mm…

  • I 200x100x7x10

    I 200x100x7x10

    —

    by

    draftsman
    in

    I 200x100x7x10 I-Beams with Tapered Inner Flange Surfaces refer to : JIS G 3192 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 200x100x7x10 Depth : 200 mm Width : 100 mm Web Thickness : 7 mm Flange Thickness : 10 mm Root Fillet Radius : 10 mm…

  • I 180x100x6x10

    I 180x100x6x10

    —

    by

    draftsman
    in

    I 180x100x6x10 I-Beams with Tapered Inner Flange Surfaces refer to : JIS G 3192 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 180x100x6x10 Depth : 180 mm Width : 100 mm Web Thickness : 6 mm Flange Thickness : 10 mm Root Fillet Radius : 10 mm…

  • I 150x125x8.5×14

    I 150x125x8.5×14

    —

    by

    draftsman
    in

    I 150x125x8.5×14 I-Beams with Tapered Inner Flange Surfaces refer to : JIS G 3192 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 150x125x8.5×14 Depth : 150 mm Width : 125 mm Web Thickness : 8.5 mm Flange Thickness : 14 mm Root Fillet Radius : 13 mm…

  • I 150x75x5.5×9.5

    I 150x75x5.5×9.5

    —

    by

    draftsman
    in

    I 150x75x5.5×9.5 I-Beams with Tapered Inner Flange Surfaces refer to : JIS G 3192 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 150x75x5.5×9.5 Depth : 150 mm Width : 75 mm Web Thickness : 5.5 mm Flange Thickness : 9.5 mm Root Fillet Radius : 9 mm…

  • I 125x75x5.5×9.5

    I 125x75x5.5×9.5

    —

    by

    draftsman
    in

    I 125x75x5.5×9.5 I-Beams with Tapered Inner Flange Surfaces refer to : JIS G 3192 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 125x75x5.5×9.5 Depth : 125 mm Width : 75 mm Web Thickness : 5.5 mm Flange Thickness : 9.5 mm Root Fillet Radius : 9 mm…

  • I 100x75x5x8

    I 100x75x5x8

    —

    by

    draftsman
    in

    I 100x75x5x8 I-Beams with Tapered Inner Flange Surfaces refer to : JIS G 3192 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 100x75x5x8 Depth : 100 mm Width : 75 mm Web Thickness : 5 mm Flange Thickness : 8 mm Root Fillet Radius : 7 mm…
