IPE 80 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 80x46x3.8×5.2 Depth : 80 mm Width : 46 mm Web Thickness : 3.8 mm Flange Thickness : 5.2 mm Root Fillet Radius : 5 mm Sectional Area…

IPE 300 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 300x150x7.1×10.7 Depth : 300 mm Width : 150 mm Web Thickness : 7.1 mm Flange Thickness : 10.7 mm Root Fillet Radius : 15 mm Sectional Area…

IPE 270 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 270x135x6.6×10.2 Depth : 270 mm Width : 135 mm Web Thickness : 6.6 mm Flange Thickness : 10.2 mm Root Fillet Radius : 15 mm Sectional Area…

IPE 240 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 240x120x6.2×9.8 Depth : 240 mm Width : 120 mm Web Thickness : 6.2 mm Flange Thickness : 9.8 mm Root Fillet Radius : 15 mm Sectional Area…

IPE 220 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 220x110x5.9×9.2 Depth : 220 mm Width : 110 mm Web Thickness : 5.9 mm Flange Thickness : 9.2 mm Root Fillet Radius : 12 mm Sectional Area…

IPE 200 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 200x100x5.6×8.5 Depth : 200 mm Width : 100 mm Web Thickness : 5.6 mm Flange Thickness : 8.5 mm Root Fillet Radius : 12 mm Sectional Area…

IPE 180 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 180x91x5.3×8 Depth : 180 mm Width : 91 mm Web Thickness : 5.3 mm Flange Thickness : 8 mm Root Fillet Radius : 9 mm Sectional Area…

IPE 160 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 160x82x5x7.4 Depth : 160 mm Width : 82 mm Web Thickness : 5 mm Flange Thickness : 7.4 mm Root Fillet Radius : 9 mm Sectional Area…

IPE 140 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 140x73x4.7×6.9 Depth : 140 mm Width : 73 mm Web Thickness : 4.7 mm Flange Thickness : 6.9 mm Root Fillet Radius : 7 mm Sectional Area…

IPE 120 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 120x64x4.4×6.3 Depth : 120 mm Width : 64 mm Web Thickness : 4.4 mm Flange Thickness : 6.3 mm Root Fillet Radius : 7 mm Sectional Area…

IPE 100 Dimensions Parallel Flange I Sections refer to : EN 10365:2017 Dimensions, Shape, Mass, and Permissible Variations of Hot Rolled Steel Sections with CAD File. Dimension : 100x55x4.1×5.7 Depth : 100 mm Width : 55 mm Web Thickness : 4.1 mm Flange Thickness : 5.7 mm Root Fillet Radius : 7 mm Sectional Area…
